Product Detailed Parameters
- Description：IC AMP D MON/STER 55.2W 48HTSSOP
- Series：-
- Mfr：Texas Instruments
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：Class D
- Output Type：1-Channel (Mono) or 2-Channel (Stereo)
- Max Output Power x Channels @ Load：55.2W x 1 @ 4Ohm, 63.5W x 2 @ 4Ohm
- Voltage - Supply：2.8V ~ 3.63V, 4.5V ~ 26.4V
- Features：Depop
- Mounting Type：Surface Mount
- Supplier Device Package：48-HTSSOP
- Package / Case：48-PowerTFSOP (0.240", 6.10mm Width)
- Operating Temperature：-25°C ~ 85°C (TA)
- Grade：-
- Qualification：-
Download product information
Overview
The TAS5760MDCAR is a stereo Class-D digital audio power amplifier manufactured by Texas Instruments. It features a QFN-32 package and accepts I2S serial digital audio inputs with sampling frequencies ranging from 8 kHz to 96 kHz. The device operates on a wide supply voltage range of 4.5 V to 24 V. Under 24 V supply conditions with a 4 Ω load, it delivers an output power of 18 W per channel at 10% THD. The amplifier achieves a total harmonic distortion plus noise (THD+N) of ≤0.05% and maintains a power conversion efficiency of ≥92%.
Feature Summary
- Accepts pure digital I2S audio input, eliminating the need for external DAC components.
- Integrates high-precision DSP processing for adaptive EQ, volume control, and bass enhancement.
- Includes comprehensive protection mechanisms such as short-circuit, over-current, and thermal shutdown.
Applications
- Consumer smart audio devices
- Home entertainment systems
- Commercial lightweight sound reinforcement
- Multimedia terminals
Procurement Notes
Verify the specific suffix 'DCAR' against official datasheets to confirm the QFN-32 package and tape-and-reel packaging configuration. Ensure compatibility with the required 4.5 V to 24 V operating voltage range and I2S interface standards before integration into the design.
Selection Notes
Select this component when designing systems requiring direct digital audio connectivity without external DACs. It is suitable for applications prioritizing low EMI, high power conversion efficiency, and integrated DSP-based audio processing within a compact QFN-32 footprint.
Part Context
This part belongs to the TAS5760MD series of closed-loop I2S input amplifiers. It shares core architecture with variants like the TAS5760MDAP but differs in package type and specific electrical characteristics defined by the manufacturer's product line segmentation.
Replacement Considerations
Consult official substitution guides for equivalent Class-D amplifiers with I2S inputs. Verify pinout compatibility and thermal performance if replacing with other TI models or competitors.
