TB-62.500MBD-T

Oscillators Overview

The TB-62.500MBD-T is a silicon MEMS oscillator manufactured by TXC Corporation, operating at a frequency of 62.5 MHz with CMOS output format. It supports a supply voltage range of 1.8V to 3.3V and maintains a frequency stability of ±50ppm across an industrial temperature range of -40°C to +85°C. The component features tri-state functionality for output enable control and is housed in a compact 5.00mm x 3.20mm surface-mount package.

Oscillators Feature Summary

• Utilizes silicon MEMS technology for robust timing performance
• Includes tri-state output capability for system power management
• Operates within a wide voltage range from 1.8V to 3.3V

Oscillators Applications

• Digital signal processing systems requiring precise clocking
• Communication equipment utilizing CMOS interface standards
• Industrial control units operating in variable thermal environments

Oscillators Procurement Notes

Verify the specific suffix requirements against the official TXC product numbering guide to ensure correct voltage and stability specifications. Confirm that the tri-state feature aligns with the target circuit design requirements before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a small form factor is required alongside CMOS compatibility. Ensure the application environment stays within the specified -40°C to +85°C operational limits to maintain the guaranteed ±50ppm frequency stability.

Oscillators Part Context

This part belongs to the TB series of standard oscillators from TXC Corporation. It represents a transition toward silicon-based timing solutions, offering advantages in size and shock resistance compared to traditional quartz alternatives while maintaining standard CMOS electrical interfaces.

Oscillators Replacement Considerations

Consult the official TXC TA-TD Part Number Guide for direct cross-references. Verify pinout compatibility and voltage levels when substituting with other MEMS oscillators from the same manufacturer family.
