TB0630A

Overview

The TB0630A is a general-purpose RF Surface Acoustic Wave (SAW) filter manufactured by TST. It operates at a center frequency of 71MHz with an insertion loss of 8dB. The component is designed for radio frequency applications requiring signal filtering in compact electronic systems.

Feature Summary

• Utilizes Surface Acoustic Wave technology for RF signal processing
• Designed as a general-purpose filter for radio frequency circuits
• Constructed for surface mount assembly on printed circuit boards

Applications

• Radio frequency signal filtering in communication devices
• General purpose RF circuit integration
• Wireless communication equipment modules

Procurement Notes

Verify the specific package configuration and lead times directly with authorized distributors or the manufacturer, as standard lead times may vary. Ensure the ordering information matches the required 12-SMD no-lead specification to guarantee compatibility with the intended surface mount design.

Selection Notes

Select this component when a 71MHz SAW filter is required for general RF applications. Consider the 8dB insertion loss and 12-SMD package dimensions during layout planning. Confirm that the operating frequency aligns precisely with the system requirements before finalizing the design.

Part Context

TST specializes in surface acoustic wave components, including RF filters and resonators. The TB0630A belongs to their SAW filter series, which supports various wireless technologies. This product line serves industries such as mobile communications, satellite positioning, and wireless local area networks.

Replacement Considerations

No public confirmed substitute part numbers are available for this component.
