TB1-10A080

Power Line Filter Modules Overview

The TB1-10A080 is a single-phase, two-stage EMC/EMI line filter module manufactured by DIT. Designed for chassis mounting, it provides filtering capabilities for electronic equipment requiring noise suppression. The unit is rated for an AC voltage of 250V and a DC voltage of 250V. It belongs to the TB1 series, which features easy connection and installation mechanisms. The component is currently in an active production status.

Power Line Filter Modules Feature Summary

• Two-stage filtering configuration for enhanced noise attenuation
• Chassis mount design for secure integration into enclosures
• Optimized characteristics for both differential mode and common mode interference

Power Line Filter Modules Applications

• High-power motor control cabinets
• Electronic equipment requiring EMI/EMC compliance
• Industrial power supply units

Power Line Filter Modules Procurement Notes

Verify the specific electrical ratings and physical dimensions against the official DIT datasheet before integration. Confirm that the chassis mounting style matches the target enclosure design. Ensure the 250V AC/DC rating aligns with the system's operational voltage requirements. Check for any specific certification marks required for the end application market.

Power Line Filter Modules Selection Notes

Select this component when a compact, two-stage solution is needed for single-phase applications. Consider the chassis mount form factor if panel or frame installation is preferred over PCB mounting. Evaluate the differential and common mode performance requirements to ensure adequate noise suppression for the specific electromagnetic environment.

Power Line Filter Modules Part Context

This part belongs to the TB1 series from DIT, which focuses on line filter modules. The series emphasizes easy connection and installation while maintaining excellent filtering characteristics. The TB1-10A080 represents a specific variant within this lineup, tailored for chassis mounting and single-phase power line protection.

Power Line Filter Modules Replacement Considerations

Consult DIT documentation for direct cross-references. Verify that any substitute maintains the two-stage architecture and identical voltage ratings. Ensure mechanical compatibility with existing chassis mounting points.
