TB1-10A0D0H

Power Line Filter Modules Overview

The TB1-10A0D0H is a single-phase EMI/EMC line filter module manufactured by DIT. It features a two-stage configuration designed for noise suppression in power lines. The component supports a rated AC voltage of 250V and operates at frequencies between 50Hz and 60Hz. It handles a maximum current of 10A. The unit utilizes terminal block connections for installation.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Single-phase design for standard power line applications
• Terminal block connection method for secure wiring

Power Line Filter Modules Applications

• Power supply input filtering
• Industrial equipment noise suppression
• Electronic device EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from DIT to confirm mechanical dimensions and mounting requirements. Ensure the operating environment matches the specified voltage and current ratings. Confirm terminal block compatibility with existing wiring infrastructure before integration into the final assembly.

Power Line Filter Modules Selection Notes

Select this model when a two-stage solution is required for single-phase systems operating at 250V and 10A. Consider the terminal block interface for ease of assembly. Evaluate the frequency range suitability for 50Hz or 60Hz mains applications.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter module series. It is engineered for electromagnetic interference reduction in electrical circuits. The manufacturer provides technical documentation detailing performance characteristics and installation guidelines for system integrators.
