TB1-16A080

Power Line Filter Modules Overview

The TB1-16A080 is a single-phase EMC/EMI line filter module manufactured by DIT. It features a two-stage filtering design with terminal block connections. The component is rated for a current of 16 A and operates at voltages up to 250 V AC within a frequency range of 50 to 60 Hz.

Power Line Filter Modules Feature Summary

• Two-stage noise attenuation architecture
• Terminal block mounting interface
• Single-phase power line filtering

Power Line Filter Modules Applications

• Medical equipment
• Industrial machinery
• Ground-current sensitive systems

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from DIT or authorized distributors to confirm exact pinout configurations and mechanical dimensions. Ensure compatibility with the target voltage and current ratings before integration. Check for any regional compliance certifications required for the intended market.

Power Line Filter Modules Selection Notes

Select this model when a compact, two-stage EMI solution is needed for single-phase circuits. Compare against similar DIT series parts like the TB1-06A080 if lower current capacity suffices. Confirm that the terminal block style matches the existing PCB or wire harness design constraints.

Power Line Filter Modules Part Context

This component belongs to DIT's TB1 series of power line filters. These modules are designed to suppress electromagnetic interference in AC power lines. The series offers various current ratings and connection types to suit different industrial and medical applications.

Power Line Filter Modules Replacement Considerations

The TB1-06A080 is a related part in the same series but supports only 6 A. Verify that the higher current rating of the TB1-16A080 is necessary for the application load.
