TB1-16A080H

Power Line Filter Modules Overview

The TB1-16A080H is a single-phase EMC/EMI line filter module manufactured by DIT. It features a two-stage filtering design intended for power line noise suppression. The component is rated for a continuous current of 16 A and operates at voltages up to 250 V AC within the 50 to 60 Hz frequency range. It utilizes a terminal block connection method for installation.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Terminal block interface for secure electrical connections
• Single-phase configuration for standard power line applications

Power Line Filter Modules Applications

• Power line noise suppression in industrial equipment
• EMC compliance for electronic devices requiring EMI reduction
• Installation in motor control cabinets

Power Line Filter Modules Procurement Notes

Verify the specific manufacturer datasheet for detailed electrical characteristics, including leakage current limits and insertion loss curves, as these parameters define the filter's performance envelope. Confirm that the terminal block specifications match the wiring requirements of the target application to ensure mechanical and electrical integrity during operation.

Power Line Filter Modules Selection Notes

Select this model when a single-phase solution with a 16 A current rating is required for 250 V AC systems. The two-stage design suggests suitability for environments demanding higher attenuation levels than single-stage filters provide. Ensure the operating frequency aligns with the 50 to 60 Hz specification for optimal performance.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter module series, which focuses on electromagnetic compatibility solutions. The TB1 series typically offers modular designs for integration into various industrial and commercial power distribution systems, providing standardized interfaces for easy installation and maintenance.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mounting hardware and terminal spacing before considering alternative models from other manufacturers.
