TB1-20A080

Power Line Filter Modules Overview

The TB1-20A080 is a single-phase EMC/EMI line filter module manufactured by DIT. It is designed for integration into power distribution systems to mitigate electromagnetic interference. The unit supports a continuous current rating of 20 A and operates at voltages up to 250 V AC within a frequency range of 50 to 60 Hz. This two-stage filtration device utilizes terminal block connections for secure electrical interfacing, ensuring compliance with emission standards in industrial environments.

Power Line Filter Modules Feature Summary

• Two-stage EMI/RFI attenuation architecture
• Terminal block mounting interface
• Single-phase power line compatibility

Power Line Filter Modules Applications

• Industrial machinery power input stages
• Medical equipment power supplies
• Commercial IT infrastructure filtering

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB1-20A080 to confirm terminal torque specifications and PCB footprint dimensions prior to integration. Ensure that the ambient operating temperature limits align with the enclosure design. Cross-reference the manufacturer's latest documentation for any RoHS or REACH compliance updates relevant to the production batch.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-phase solution is required for 20 A applications. The terminal block interface simplifies wiring compared to solder-mount alternatives. Evaluate the insertion loss characteristics against system-specific noise profiles to ensure adequate attenuation without compromising signal integrity on adjacent lines.

Power Line Filter Modules Part Context

DIT specializes in electromagnetic compatibility solutions, including filters and shielding products. The TB1 series represents their modular approach to power line filtering, allowing engineers to customize protection levels. This model fits within their standard catalog for general-purpose industrial filtering needs.

Power Line Filter Modules Replacement Considerations

Consult DIT technical support for direct cross-references. Verify that substitute modules match the 20 A current rating and 250 VAC voltage class. Ensure physical dimensions and terminal spacing are compatible with existing panel layouts.
