TB1-20A080H

Power Line Filter Modules Overview

The TB1-20A080H is a single-phase EMC/EMI line filter module manufactured by DIT. It features a two-stage design providing both common-mode and differential-mode noise suppression. The unit is rated for a continuous current of 20 A and operates at voltages up to 250 V AC within the 50–60 Hz frequency range. It utilizes terminal block mounting for secure installation in general-purpose power systems requiring robust interference mitigation.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Integrated common-mode and differential-mode suppression capabilities
• Terminal block mounting configuration for reliable electrical connection

Power Line Filter Modules Applications

• General-purpose 250V AC power systems
• Equipment requiring EMI/EMC compliance
• Industrial control panels

Power Line Filter Modules Procurement Notes

Verify the specific part number TB1-20A080H against official DIT documentation to confirm compatibility with your system's voltage and current requirements. Ensure that the terminal block interface matches your wiring specifications. Cross-reference datasheets for precise insertion loss characteristics and thermal ratings before integration into final assemblies.

Power Line Filter Modules Selection Notes

Select this component when a dedicated two-stage solution is required for 20 A applications. Consider the physical dimensions and terminal block orientation during PCB or chassis layout planning. Validate that the 250 V rating aligns with the maximum operating voltage of the connected load to ensure safety and performance longevity.

Power Line Filter Modules Part Context

This model belongs to the TB1 series of power line filter modules from DIT, designed for electromagnetic interference reduction. The series typically offers various current and voltage ratings to suit different industrial and commercial power distribution needs, focusing on compact form factors with high-performance filtering stages.

Power Line Filter Modules Replacement Considerations

Consult official DIT substitution guides for verified equivalents. Generic filters may not match the specific two-stage attenuation profile or terminal block mechanical constraints of the TB1-20A080H.
