TB1-20A0D0

Power Line Filter Modules Overview

The TB1-20A0D0 is a single-phase power line filter module manufactured by DIT. It features a two-stage configuration designed for chassis mounting. The component supports rated voltages of 250V AC and 250V DC, with a current rating of 20A. This EMC/EMI filter module is intended to suppress electromagnetic interference in power lines.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Chassis mount design for secure installation
• Supports both AC and DC voltage applications

Power Line Filter Modules Applications

• Power line EMI/EMC filtering
• Industrial equipment noise suppression
• Chassis-mounted power supply protection

Power Line Filter Modules Procurement Notes

Verify the specific electrical requirements against the official datasheet before procurement. Confirm that the 20A current rating and 250V voltage limits align with your system's operational parameters. Ensure the chassis mounting style matches your enclosure design. Check for any specific compliance certifications required for your target market.

Power Line Filter Modules Selection Notes

Select this model when a two-stage solution is required for significant noise reduction in 20A circuits. Consider the physical dimensions for chassis integration. Evaluate if the single-phase configuration meets your power distribution needs. Compare performance metrics with alternative filters if higher current or voltage ratings are necessary.

Power Line Filter Modules Part Context

This component belongs to DIT's series of power line filter modules. These modules are engineered for robust electromagnetic compatibility in demanding environments. The product line focuses on providing reliable noise attenuation for sensitive electronic systems connected to main power supplies.
