TB1-30A080

Power Line Filter Modules Overview

The DIT TB1-30A080 is a single-phase EMC/EMI line filter module designed for power line protection. It features a two-stage filtering architecture and utilizes terminal block connections for installation. The unit is rated for a continuous current of 30 A and operates at voltages up to 250V within the 50 to 60Hz frequency range. This chassis-mount component provides noise suppression capabilities for electrical systems requiring compliance with electromagnetic interference standards.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Terminal block connection method for secure wiring
• Chassis-mount design for industrial integration

Power Line Filter Modules Applications

• High-power motor control cabinets
• Industrial machinery power supplies
• Electrical systems requiring EMI/EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific voltage and current ratings against your system requirements before procurement. Confirm that the terminal block interface matches your existing wiring infrastructure. Ensure the chassis-mount dimensions fit your enclosure space. Check for any specific certification requirements relevant to your region's regulatory standards.

Power Line Filter Modules Selection Notes

Select this model when a two-stage solution is required for significant noise reduction in single-phase applications. Consider the 30A rating to ensure adequate capacity for your load. Evaluate the terminal block style against available connection tools. Compare physical dimensions against alternative mounting options if space is constrained.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter module series, which focuses on electromagnetic compatibility solutions. These modules are engineered to mitigate conducted emissions and improve immunity in sensitive electronic environments. The product line typically serves industrial and commercial sectors where power quality is critical.
