TB1-30A080H

Power Line Filter Modules Overview

The TB1-30A080H is a single-phase EMC/EMI power line filter module manufactured by DIT. It features a two-stage filtering design intended to suppress electromagnetic interference in AC power circuits. The unit is rated for a continuous current of 30 A and operates at voltages up to 250 V. It supports standard mains frequencies of 50 Hz to 60 Hz. The component utilizes a chassis mount configuration with terminal block connections for secure integration into electrical systems.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Terminal block connection interface for secure wiring
• Chassis mount form factor for stable installation

Power Line Filter Modules Applications

• Single-phase AC power line filtering
• EMC/EMI noise reduction in industrial equipment
• Power supply input stages for sensitive electronics

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB1-30A080H to confirm exact attenuation curves and safety certifications prior to procurement. Ensure that the terminal block specifications match the existing panel layout requirements. Confirm that the 30 A current rating aligns with the maximum load expectations of the target circuit to prevent thermal issues during operation.

Power Line Filter Modules Selection Notes

Select this component when a robust, two-stage solution is required for single-phase applications. The 30 A rating makes it suitable for higher-power loads compared to lower-amperage alternatives. Consider the chassis mounting style if space constraints or vibration resistance are critical factors in the enclosure design. Verify compatibility with 250 V systems before finalizing the selection.

Power Line Filter Modules Part Context

This part belongs to the DIT power line filter module series, which focuses on electromagnetic compatibility solutions. These modules are designed to integrate directly into power distribution systems to mitigate conducted emissions. The TB1-30A080H represents a specific capacity within this lineup, tailored for applications requiring significant current handling alongside effective interference suppression.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation for direct cross-references. Ensure any substitute maintains the 30 A rating, two-stage topology, and terminal block interface to preserve system performance and mechanical fit without redesigning the mounting structure.
