TB1-30A0D0

Power Line Filter Modules Overview

The TB1-30A0D0 is a single-phase EMC/EMI line filter module manufactured by DIT. It is designed for chassis mounting and features a two-stage filtering architecture to suppress electromagnetic interference in power lines. The component operates at a rated current of 30 A and supports voltages up to 250 V AC within a frequency range of 50 to 60 Hz. Connection is facilitated via terminal block interfaces, ensuring secure integration into industrial power distribution systems requiring certified noise reduction.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Chassis-mount design for stable installation
• Terminal block connection interface

Power Line Filter Modules Applications

• Industrial power distribution units
• EMC-compliant machinery enclosures
• Power supply input stages

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from DIT or authorized distributors to confirm compliance with regional safety standards such as UL or CE. Ensure the terminal block specifications match the wiring requirements of the target application. Cross-reference the 30 A rating against peak load conditions to prevent thermal overload during operation.

Power Line Filter Modules Selection Notes

Select this model when a single-phase solution is required for applications demanding 30 A capacity and 250 VAC compatibility. The two-stage design offers superior attenuation compared to single-stage alternatives. Confirm that the chassis mounting dimensions fit the available enclosure space and that the terminal block orientation aligns with the internal wiring layout.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter series, which specializes in EMI/RFI suppression for electronic equipment. The TB1-30A0D0 variant specifically addresses high-current single-phase applications where strict electromagnetic compatibility is mandated by regulatory frameworks for industrial and commercial hardware.

Power Line Filter Modules Replacement Considerations

Consult DIT documentation for direct cross-references. Verify that any substitute maintains the 30 A current rating, 250 VAC voltage limit, and two-stage filtering topology to ensure equivalent performance.
