TB1-30A0D0H

Power Line Filter Modules Overview

The TB1-30A0D0H is a single-phase EMC/EMI line filter module manufactured by DIT. It features a two-stage filtering design with terminal connections, rated for 30 A current and 250 V AC at 50–60 Hz. The unit utilizes a metal housing for effective shielding against high-voltage pulses and provides robust common-mode and differential-mode attenuation characteristics.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Metal housing construction providing superior electromagnetic shielding
• Effective attenuation of high-voltage pulses and both common-mode and differential-mode interference

Power Line Filter Modules Applications

• Industrial equipment such as CNC machines
• Inverters and converters
• Telecommunications equipment
• Factory automation (FA) devices
• Elevator systems

Power Line Filter Modules Procurement Notes

Verify the specific part number TB1-30A0D0H against official DIT documentation to confirm single-phase rating and terminal type. Ensure compatibility with 250 V AC input requirements. Confirm that the metal housing dimensions fit the intended enclosure space. Check for required certifications like CE or SEMKO+ENEC if applicable to your region. Validate current handling capabilities for your specific load profile before procurement.

Power Line Filter Modules Selection Notes

Select this model when high-voltage pulse attenuation and strong shielding are critical for single-phase applications. The two-stage design offers superior performance compared to single-stage filters. Consider the metal housing for environments requiring robust physical protection and EMI containment. Ensure the 30 A rating exceeds the maximum operational current of the protected circuit to prevent overheating or failure.

Power Line Filter Modules Part Context

This component belongs to the DIT TB series of power line filter modules, specifically designed for industrial and commercial electrical systems. The TB1 variant denotes single-phase configuration within this product family. These filters are engineered to meet stringent EMC standards, ensuring reliable operation in electrically noisy environments typical of modern industrial automation and power electronics applications.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers for the DIT TB1-30A0D0H are not available in the provided source material. Verify compatibility with any alternative components by matching electrical ratings, mounting style, and shielding requirements against original specifications.
