TB1-40A080

Power Line Filter Modules Overview

The DIT TB1-40A080 is a single-phase EMC/EMI line filter module designed for power line noise suppression. It features a two-stage filtering architecture to attenuate electromagnetic interference across the spectrum. The component supports a continuous current rating of 40 A and operates at voltages up to 250 V AC within standard 50 Hz to 60 Hz frequency ranges. It utilizes a terminal block mounting interface for secure electrical connections.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Terminal block mounting interface for secure installation

Power Line Filter Modules Applications

• Power line noise suppression in industrial equipment
• EMC compliance for single-phase power systems
• Electromagnetic interference reduction in sensitive electronics

Power Line Filter Modules Procurement Notes

Verify the exact part number suffix against official manufacturer documentation, as variants such as TB1-40A080H may exist with different mechanical or electrical specifications. Ensure compatibility with the target voltage and current requirements before procurement. Cross-reference datasheets to confirm terminal block orientation and mounting dimensions match the design constraints.

Power Line Filter Modules Selection Notes

Select this component based on its 40 A current capacity and two-stage filtering performance for single-phase applications. Evaluate the terminal block interface for ease of integration into existing wiring harnesses. Confirm that the 250 V rating aligns with the system's maximum operating voltage and that the physical footprint fits the designated enclosure space.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter module series, which focuses on EMC/EMI mitigation for AC power inputs. It is engineered for robust noise suppression in environments requiring strict electromagnetic compatibility standards. The module integrates passive filtering elements to protect downstream equipment from conducted interference.

Power Line Filter Modules Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify direct compatibility with any alternative components by matching current ratings, voltage limits, and filtering stage configurations.
