TB1-40A080H

Power Line Filter Modules Overview

The TB1-40A080H is a single-phase EMC/EMI line filter module manufactured by DIT. It features a two-stage filtering architecture designed for chassis mounting applications. The component supports a continuous current rating of 40 A and operates with voltage ratings up to 250 VAC at frequencies between 50 Hz and 60 Hz. Terminal connections are provided via a terminal block interface, ensuring secure electrical integration within power distribution systems.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Chassis mount design for stable mechanical installation
• Terminal block interface for reliable electrical connectivity

Power Line Filter Modules Applications

• Industrial power supply units
• Electromagnetic compatibility (EMC) compliance systems
• Power distribution equipment requiring EMI reduction

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB1-40A080H to confirm detailed electrical characteristics and mechanical dimensions prior to procurement. Ensure that the mounting configuration aligns with the chassis specifications of the target application. Cross-reference the terminal block type with existing wiring harnesses to guarantee physical compatibility and proper connection integrity during assembly.

Power Line Filter Modules Selection Notes

Select this component when high-current single-phase filtering is required for industrial environments. The 40 A rating accommodates substantial load currents while maintaining effective EMI suppression through its dual-stage design. Consider the chassis mounting requirement and terminal block interface when evaluating alternative solutions for space-constrained or vibration-prone installations.

Power Line Filter Modules Part Context

This part belongs to the series of single-phase EMC/EMI line filters produced by DIT. These modules are engineered to mitigate electromagnetic interference in AC power lines, supporting standard 50/60 Hz operations. The product line emphasizes robust construction suitable for demanding industrial settings where reliable noise filtration is critical for system stability.
