TB1-40A0D0

$28.39

Description：LINE FILTER 250VAC/VDC 40A CHASS
Series：TB1
Mfr：DIT
Package：Box

SKU:b37b1637451b Category: Power Line Filter Modules Brand: DIT

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TB1-40A0D0 is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 250VAC/VDC 40A CHASS. Review the specifications below when checking this part for your BOM.

Power Line Filter Modules specifications for TB1-40A0D0

Description：LINE FILTER 250VAC/VDC 40A CHASS
Series：TB1
Mfr：DIT
Package：Box
Filter Type：Single Phase
Configuration：Two Stage
Voltage - Rated DC：250V
Voltage - Rated AC：250V
Current：40 A
Frequency - Operating：50 ~ 60Hz
Applications：General Purpose
Approval Agency：CE, cCSAus, ENEC, SEMKO
Operating Temperature：-25°C ~ 85°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Power Line Filter Modules datasheet and documents for TB1-40A0D0

TB1-40A0D0

Power Line Filter Modules Overview

The TB1-40A0D0 is a single-phase EMC/EMI line filter module manufactured by Dong Il Technology. It features a two-stage filtering design with terminal block connections, rated for 40 A current and 250 V voltage at 50 ~ 60 Hz frequencies.

Power Line Filter Modules Feature Summary

Two-stage filtering architecture
Terminal block connection method
Dual-mode interference suppression

Power Line Filter Modules Applications

Medical equipment
Industrial systems
Ground-current sensitive applications

Power Line Filter Modules Procurement Notes

Verify the manufacturer as Dong Il Technology Ltd. Confirm the part number TB1-40A0D0 matches the 40 A rating and single-phase specification. Ensure compatibility with terminal block mounting requirements for your specific installation environment.

Power Line Filter Modules Selection Notes

Select this component when a compact, two-stage EMI solution is required for single-phase circuits. The terminal block interface simplifies integration into existing power distribution panels without requiring specialized wiring harnesses or soldering processes.

Power Line Filter Modules Part Context

This module belongs to the TB1 series of power line filters from Dong Il Technology. These components are engineered to reduce conducted emissions in industrial and medical power systems, providing reliable noise attenuation through a structured two-stage design.
