TB4-016G

$135.41

Description：LINE FILTER 16A CHASSIS MOUNT
Series：TB4
Mfr：DIT
Package：Box

SKU:221f2fcd8f87 Category: Power Line Filter Modules Brand: DIT

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TB4-016G is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 16A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.

Power Line Filter Modules specifications for TB4-016G

Description：LINE FILTER 16A CHASSIS MOUNT
Series：TB4
Mfr：DIT
Package：Box
Filter Type：Three Phase (Wye)
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：-
Current：16 A
Frequency - Operating：50 ~ 60Hz
Applications：General Purpose
Approval Agency：CE, CSA, ENEC, SEMKO
Operating Temperature：-25°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：290 V
Voltage - Rated AC (Phase to Phase)：500 V

Power Line Filter Modules datasheet and documents for TB4-016G

TB4-016G

Power Line Filter Modules Overview

The DIT TB4-016G is a three-phase filter component from the TB4 series, designed for industrial applications. It features epoxy resin potting and a metal housing to provide effective shielding against high-voltage pulses. The unit offers excellent filtering characteristics for both differential mode and common mode noise. Certified under CE, SEMKO, and ENEC safety standards, it ensures reliable operation in demanding environments such as CNC machines, inverters, converters, telecommunications equipment, factory automation systems, and elevators.

Power Line Filter Modules Feature Summary

Epoxy resin potting construction
Metal housing with effective shielding
High attenuation of high-voltage pulses
Differential and common mode filtering

Power Line Filter Modules Applications

CNC machines
Inverters and converters
Telecommunications equipment
Factory automation (FA) devices
Elevators

Power Line Filter Modules Procurement Notes

Verify the specific model designation TB4-016G against official DIT documentation to confirm compatibility with your system's voltage and current requirements. Ensure that the required safety certifications (CE, SEMKO, ENEC) are explicitly listed for this part number in the manufacturer's datasheet before procurement.

Power Line Filter Modules Selection Notes

Select this component when high-voltage pulse attenuation and robust electromagnetic interference suppression are required for three-phase power lines. The metal housing and epoxy potting make it suitable for industrial settings where physical durability and electrical isolation are critical for long-term reliability.

Power Line Filter Modules Part Context

This part belongs to the DIT TB4 series of three-phase filters. These components are engineered to mitigate electrical noise in industrial power systems. The series utilizes epoxy resin encapsulation and metallic enclosures to enhance shielding effectiveness and protect internal components from environmental factors.
