TB4-080GR

Power Line Filter Modules Overview

The TB4-080GR is a three-phase Wye EMC/EMI line filter module manufactured by DIT. It is rated for a continuous current of 80 A and operates at frequencies of 50 to 60 Hz. The unit utilizes a single-stage filtering design and features terminal block connections for installation.

Power Line Filter Modules Feature Summary

• Designed for three-phase Wye input systems with phase-to-neutral or phase-to-ground references
• Provides electromagnetic compatibility (EMC) and radio frequency interference (EMI) suppression
• Utilizes a single-stage filtering architecture

Power Line Filter Modules Applications

• Industrial power distribution systems requiring EMI suppression
• Three-phase machinery with Wye-connected inputs
• Equipment sensitive to conducted electromagnetic noise

Power Line Filter Modules Procurement Notes

Verify the specific part number TB4-080GR against official DIT documentation to confirm the terminal block interface and 80 A rating. Ensure the application system matches the required three-phase Wye configuration. Cross-reference datasheets for precise electrical characteristics and mounting requirements before procurement.

Power Line Filter Modules Selection Notes

Select this component for applications requiring 80 A capacity in a three-phase Wye topology. Confirm that the terminal block connection method aligns with the system wiring infrastructure. Validate that the single-stage filtering performance meets the specific EMI/EMC mitigation requirements of the target equipment.

Power Line Filter Modules Part Context

This component belongs to the TB4 series of power line filter modules from DIT. The series includes variants such as the TB4-020H and TB4-120HR, offering different current ratings and chassis or terminal block configurations for various industrial filtering needs.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with existing systems before considering alternative models.
