TB4-120GR is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 120A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for TB4-120GR
- Description：LINE FILTER 120A CHASSIS MOUNT
- Series：TB4
- Mfr：DIT
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：120 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, CSA, ENEC, SEMKO
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：290 V
- Voltage - Rated AC (Phase to Phase)：500 V
Power Line Filter Modules datasheet and documents for TB4-120GR
Power Line Filter Modules Overview
The TB4-120GR is a three-phase (Wye) EMC/EMI line filter module manufactured by DIT. It is designed for AC power lines operating at 50 to 60Hz with a rated current of 120 A. The unit features a single-stage filtering architecture and utilizes a terminal block connection method. This component is constructed as a chassis-mount device intended for integration into industrial electrical systems requiring electromagnetic interference suppression.
Power Line Filter Modules Feature Summary
- Provides electromagnetic compatibility filtering for three-phase power circuits
- Utilizes a single-stage design for noise attenuation
- Features terminal block connections for secure wiring
Power Line Filter Modules Applications
- Industrial machinery power supply conditioning
- Three-phase motor drive input stages
- Electrical panels requiring EMI suppression
Power Line Filter Modules Procurement Notes
Verify the specific datasheet version for the TB4-120GR to confirm mechanical dimensions and terminal specifications. Ensure the application voltage and frequency align with the 50-60Hz rating. Confirm that the 120 A current capacity meets the load requirements. Check for any required mounting hardware or accessories not included in the standard module package.
Power Line Filter Modules Selection Notes
Select this model when a three-phase Wye configuration is required for high-current applications up to 120 A. The single-stage design offers a balance between performance and physical footprint. Ensure the installation environment supports chassis mounting. Verify that the terminal block interface matches the existing wiring infrastructure before procurement.
Power Line Filter Modules Part Context
This component belongs to the TB4 series of power line filter modules from DIT. The series provides EMC solutions for various industrial applications. The TB4-120GR specifically addresses high-current three-phase needs. It complements other components in DIT's electromagnetic compatibility product lineup.
Power Line Filter Modules Replacement Considerations
No public substitute part numbers are confirmed for this specific model. Consult DIT technical support for equivalent alternatives if sourcing is unavailable.
