TB4-120HR

Power Line Filter Modules Overview

The TB4-120HR is a three-phase (Wye) EMC/EMI line filter module designed for industrial power applications. It operates at a rated current of 120 A and supports frequencies of 50 to 60 Hz. The unit functions as a single-stage filter to suppress electromagnetic interference in AC power lines.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for three-phase power systems
• Engineered for high-current industrial environments

Power Line Filter Modules Applications

• Industrial machinery power conditioning
• Three-phase motor drive input filtering
• Factory automation power distribution

Power Line Filter Modules Procurement Notes

Verify the exact datasheet specifications directly with the manufacturer or authorized distributor before procurement. Confirm that the 120 A rating and Wye configuration match your specific system requirements. Ensure compatibility with 50/60 Hz operation. Request official documentation to validate performance metrics and physical dimensions.

Power Line Filter Modules Selection Notes

Select this component when a dedicated three-phase EMI filter is required for circuits carrying up to 120 Amperes. Ensure the installation environment accommodates the module's thermal and spatial constraints. Verify that the Wye topology aligns with the existing power infrastructure design.

Power Line Filter Modules Part Context

This part belongs to the category of power line filter modules. These components are essential for maintaining power quality and compliance with electromagnetic compatibility standards in sensitive electronic and industrial equipment.

Power Line Filter Modules Replacement Considerations

Consult official substitution lists from the manufacturer for verified equivalent parts. Do not assume cross-compatibility with other brands without validating electrical ratings and mounting configurations.
