TB4-150GR

Power Line Filter Modules Overview

The DIT TB4-150GR is a three-phase (Wye) EMC/EMI line filter designed for industrial power applications. It supports a continuous current rating of 150 A and operates at frequencies between 50 Hz and 60 Hz. The unit utilizes a single-stage filtering architecture to mitigate electromagnetic interference in AC power systems. This component employs a terminal block connection method for electrical integration and features a base mount configuration for secure chassis installation.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for three-phase Wye configurations
• Utilizes a single-stage filtering design for noise reduction
• Features terminal block connections for circuit integration

Power Line Filter Modules Applications

• Industrial power distribution systems
• Chassis-mounted equipment requiring EMI mitigation
• Three-phase AC power line filtering

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB4-150GR to confirm detailed electrical characteristics and mechanical dimensions. Ensure compatibility with the target mounting surface and terminal block requirements before procurement. Cross-reference the manufacturer's documentation for any updates regarding RoHS compliance status or environmental operating limits.

Power Line Filter Modules Selection Notes

Select this component when a 150 A capacity is required for three-phase Wye systems. Consider the terminal block interface for wiring convenience and the base mount style for structural stability. Evaluate the single-stage performance against specific EMI attenuation requirements to ensure adequate noise suppression for the intended application environment.

Power Line Filter Modules Part Context

This model belongs to the DIT TB4 series of power line filter modules. These components are engineered for robust performance in demanding industrial environments. The series typically offers various current ratings to accommodate different power levels while maintaining consistent form factors and mounting styles for standardized integration.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation for confirmed substitute part numbers within the TB4 series. Verify that alternative models match the 150 A current rating and three-phase Wye configuration. Ensure mechanical mounting and terminal block interfaces remain compatible during substitution.
