TB4-200GR is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 200A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for TB4-200GR
- Description：LINE FILTER 200A CHASSIS MOUNT
- Series：TB4
- Mfr：DIT
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：200 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, CSA, ENEC, SEMKO
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：290 V
- Voltage - Rated AC (Phase to Phase)：500 V
Power Line Filter Modules datasheet and documents for TB4-200GR
Power Line Filter Modules Overview
The TB4-200GR is a three-phase (Wye) EMC/EMI line filter module manufactured by DIT. It is rated for a current of 200 A and operates at frequencies of 50 to 60 Hz. The unit features a single-stage design with terminal block connections. This component is engineered for power line filtering applications requiring robust electromagnetic interference suppression in industrial electrical systems.
Power Line Filter Modules Feature Summary
- Provides three-phase Wye configuration for comprehensive power line filtering
- Engineered for high-current handling up to 200 Amperes
- Utilizes terminal block connection method for secure installation
Power Line Filter Modules Applications
- Industrial power distribution systems
- Electromagnetic compatibility (EMC) compliance setups
- Heavy machinery power input stages
Power Line Filter Modules Procurement Notes
Verify the specific datasheet version for the TB4-200GR to confirm exact dimensional tolerances and terminal specifications. Ensure that the mounting hardware and wiring terminals are compatible with the 200 A current rating before integration. Cross-reference the manufacturer's documentation for any updates regarding environmental operating limits or certification status.
Power Line Filter Modules Selection Notes
Select this model when a three-phase Wye topology is required for high-current applications. The 200 A rating dictates suitability for heavy-duty industrial loads. Confirm that the system frequency aligns with the 50 to 60 Hz operational range. Evaluate the terminal block interface against existing panel wiring infrastructure to ensure mechanical and electrical compatibility.
Power Line Filter Modules Part Context
This component belongs to the TB4 series of power line filter modules from DIT. The series offers various current ratings, with the TB4-200GR specifically addressing the 200 A requirement. It serves as a critical element for noise reduction in AC power lines within industrial environments.
Power Line Filter Modules Replacement Considerations
Consult official DIT documentation for direct cross-references. Verify that any substitute maintains the three-phase Wye configuration and 200 A current capacity.
