TB4-200HR

Power Line Filter Modules Overview

The TB4-200HR is a three-phase (Wye) EMC/EMI line filter module manufactured by DIT. It is designed for AC power systems operating at 50 to 60Hz with a rated current capacity of 200 Amperes. The unit features a chassis-mount configuration, providing robust electromagnetic interference suppression for industrial power distribution networks.

Power Line Filter Modules Feature Summary

• Provides effective attenuation of electromagnetic interference in three-phase power lines
• Features a metal enclosure for enhanced shielding performance
• Designed for high-current industrial applications

Power Line Filter Modules Applications

• Industrial equipment power filtering
• Inverter and converter input stages
• Machine tool electrical systems

Power Line Filter Modules Procurement Notes

Verify the specific datasheet for detailed impedance curves and insertion loss specifications. Confirm that the Wye configuration matches your system neutral requirements. Ensure chassis mounting provisions align with your panel design constraints before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this model when a 200A continuous current rating is required for three-phase Wye systems. Consider thermal management capabilities within the installation environment. Evaluate space constraints for chassis-mounted units compared to DIN-rail alternatives.

Power Line Filter Modules Part Context

This component belongs to DIT's series of power line filter modules. These units are engineered to meet stringent EMC standards for industrial machinery. The product line typically includes various current ratings to accommodate different power distribution scales.

Power Line Filter Modules Replacement Considerations

Cross-reference with other DIT models in the TB4 series for alternative current ratings. Verify compatibility with existing mounting hardware and terminal configurations when substituting similar filters from other manufacturers.
