TB4-700GR

Power Line Filter Modules Overview

The TB4-700GR is a three-phase (Wye) EMC/EMI line filter module manufactured by DIT. It is rated for a current of 700 A and operates at frequencies between 50 Hz and 60 Hz. The unit utilizes a single-stage design with terminal block connections. It features an operating temperature range from -25°C to 100°C. The component holds certifications including CE, CSA, ENEC, and SEMKO.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for three-phase power systems
• Designed for chassis or base mounting applications
• Utilizes terminal block connection method for installation

Power Line Filter Modules Applications

• General purpose industrial power filtering
• Three-phase Wye system noise reduction
• Industrial equipment EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB4-700GR to confirm exact physical dimensions and terminal specifications. Ensure that the required current rating of 700 A aligns with the system load requirements. Confirm that the operating temperature range of -25°C to 100°C meets the environmental conditions of the intended installation site.

Power Line Filter Modules Selection Notes

Select this component when a high-current three-phase filter is required for Wye configurations. The 700 A rating distinguishes it from lower capacity variants in the TB4 series. Consider the terminal block interface for wiring compatibility. Verify that the single-stage topology provides sufficient attenuation for the specific noise profile encountered in the application.

Power Line Filter Modules Part Context

This part belongs to the TB4 series of power line filter modules from DIT. The series includes various current ratings such as 250 A and 600 A. These filters are designed for industrial environments requiring robust EMC performance. The TB4-700GR represents the higher end of the current capacity spectrum within this product family.

Power Line Filter Modules Replacement Considerations

Direct substitutes may include other models within the DIT TB4 series with similar current ratings. Cross-referencing physical mounting dimensions and terminal block types is essential. Verify that alternative components meet the same certification requirements (CE, CSA, ENEC, SEMKO) for global deployment.
