TB6-4400BC62

Power Line Filter Modules Overview

The DIT TB6-4400BC62 is a three-phase power line filter module designed for industrial applications. It features a metal housing with effective shielding and epoxy resin potting. The component provides significant attenuation against high-voltage pulses and offers excellent filtering characteristics for both differential mode and common mode noise. It is rated for AC voltage and supports high current capacities, ensuring stable operation in demanding environments such as CNC machines, inverters, and elevators.

Power Line Filter Modules Feature Summary

• Epoxy resin potting for durability
• Metal housing with effective shielding
• High-voltage pulse attenuation
• Differential and common mode filtering

Power Line Filter Modules Applications

• CNC machines
• Inverters and converters
• Telecommunications equipment
• Factory automation devices
• Elevators

Power Line Filter Modules Procurement Notes

Verify the specific part number suffix to ensure compatibility with your system requirements. Confirm that the mounting configuration matches your chassis design. Check for relevant safety certifications such as CE or SEMKO+ENEC if required by your regional regulations. Ensure the thermal management plan accounts for the specified temperature rise under full load conditions.

Power Line Filter Modules Selection Notes

Select this model when high-power motor control cabinets require robust EMI/EMI suppression. Consider the metal enclosure for superior shielding effectiveness compared to plastic alternatives. Evaluate the current rating against peak operational loads to prevent overheating. Verify the physical dimensions fit within the available space constraints of the installation panel.

Power Line Filter Modules Part Context

This component belongs to the TB6-2/4 series of three-phase filters manufactured by DIT (Higashi Nippon Giken). These filters are engineered for industrial power quality improvement. The series utilizes advanced materials to handle high currents while maintaining low voltage drop. They are widely used in sectors requiring strict electromagnetic compatibility standards.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the TB6-2/4 series that match the current and voltage ratings. Ensure any replacement maintains the same mounting style and terminal configuration. Verify that alternative models offer comparable shielding and pulse attenuation capabilities.
