TB6-5016D3DG

Power Line Filter Modules Overview

The TB6-5016D3DG is a three-phase filter from the TB6-2/4 series manufactured by Shenzhen Dongri Jiken (DIT). It features an epoxy resin encapsulation and a metal housing for effective shielding. The unit provides significant attenuation against high-voltage pulses and delivers excellent filtering characteristics for both differential-mode and common-mode noise. Designed for industrial applications, it ensures signal integrity in sensitive equipment environments.

Power Line Filter Modules Feature Summary

• Epoxy resin encapsulation for durability
• Metal housing with superior shielding
• High-voltage pulse attenuation
• Effective differential and common-mode filtering

Power Line Filter Modules Applications

• CNC machines
• Inverters
• Converters
• Telecommunications equipment
• Factory automation devices

Power Line Filter Modules Procurement Notes

Verify the specific model suffix to ensure compatibility with existing system requirements. Confirm that the manufacturer designation matches Shenzhen Dongri Jiken specifications. Check for relevant safety certifications such as CE or SEMKO+ENEC if required by local regulations. Ensure the physical dimensions fit the intended installation space.

Power Line Filter Modules Selection Notes

Select this component when robust electromagnetic interference suppression is required for three-phase power lines. The metal enclosure offers enhanced protection compared to non-shielded alternatives. Consider the epoxy encapsulation for environments requiring resistance to moisture or chemical exposure. Evaluate the need for high-voltage pulse handling capabilities in the target application.

Power Line Filter Modules Part Context

This part belongs to the TB6-2/4 series of three-phase filters. These components are engineered to mitigate electrical noise in industrial settings. The series utilizes advanced filtering techniques to maintain power quality. The design focuses on reliability and long-term performance in demanding operational conditions.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers for the TB6-5016D3DG are not available in the provided documentation. Verify electrical parameters and mounting configurations before considering alternative models from other manufacturers.
