TB6-5016D3DH is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 16A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for TB6-5016D3DH
- Description：LINE FILTER 16A CHASSIS MOUNT
- Series：TB6-2,5 G/H
- Mfr：DIT
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：16 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, ENEC, SEMKO, UL, UR
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：290 V
- Voltage - Rated AC (Phase to Phase)：500 V
Power Line Filter Modules datasheet and documents for TB6-5016D3DH
Power Line Filter Modules Overview
The TB6-5016D3DH is a three-phase (Delta) EMC/EMI line filter module manufactured by DIT. It is rated for 16 A current and operates at frequencies of 50 to 60 Hz. The component features a two-stage filtering architecture designed to suppress electromagnetic interference in power lines. It utilizes terminal block connections for installation.
Power Line Filter Modules Feature Summary
- Two-stage EMI/EMC filtering architecture
- Terminal block connection interface
Power Line Filter Modules Applications
- High-power motor control cabinets
- Industrial equipment such as CNC machines
- Inverter systems
Power Line Filter Modules Procurement Notes
Verify the specific part number TB6-5016D3DH against official DIT documentation to confirm the three-phase Delta configuration and 16 A rating. Ensure compatibility with 50-60 Hz operational environments. Confirm terminal block mounting requirements before procurement.
Power Line Filter Modules Selection Notes
Select this module for applications requiring two-stage suppression in three-phase Delta circuits. Verify that the 16 A current rating meets system load requirements. Ensure the terminal block interface aligns with existing wiring infrastructure.
Power Line Filter Modules Part Context
This component belongs to the DIT power line filter module series, specifically designed for industrial EMC/EMI mitigation. It addresses noise suppression needs in high-power electronic systems operating on standard AC frequencies.
Power Line Filter Modules Replacement Considerations
No public substitute part numbers are confirmed for this specific model. Consult DIT technical support for verified alternatives if sourcing is unavailable.
