TB6-5020D3DH

Power Line Filter Modules Overview

The TB6-5020D3DH is a two-stage EMC/EMI power line filter module manufactured by DIT. Designed for chassis mounting, this component supports a continuous current rating of 20 A and operates within a frequency range of 50 to 60 Hz. It is configured for three-phase Delta systems and utilizes terminal block connections for integration into industrial power distribution networks.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Chassis mount design for secure mechanical installation
• Terminal block interface for simplified wiring

Power Line Filter Modules Applications

• Industrial machinery power conditioning
• Three-phase Delta system noise suppression
• EMC compliance in electrical enclosures

Power Line Filter Modules Procurement Notes

Verify the exact suffix against official DIT documentation to confirm terminal type and voltage ratings. Confirm chassis mounting dimensions and torque specifications prior to integration. Ensure compatibility with the specific three-phase Delta configuration required by the target application circuit.

Power Line Filter Modules Selection Notes

Select this model specifically for applications requiring 20 A capacity in three-phase Delta configurations. Evaluate the two-stage filtering performance against specific EMI/EMC standards relevant to the deployment environment. Verify that the chassis mounting style aligns with the available space and thermal management requirements of the equipment enclosure.

Power Line Filter Modules Part Context

This component belongs to DIT's series of power line filter modules designed for industrial environments. The manufacturer specializes in measurement technology and process monitoring solutions, leveraging expertise from the aviation electronics sector to produce reliable electromagnetic interference suppression components.

Power Line Filter Modules Replacement Considerations

Cross-reference part numbers such as TB6-5020D3DG for potential functional equivalents. Verify that any substitute maintains the identical 20 A rating, three-phase Delta configuration, and chassis mounting form factor to ensure seamless integration without redesign.
