TB6-5030D3DH is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 30A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for TB6-5030D3DH
- Description：LINE FILTER 30A CHASSIS MOUNT
- Series：TB6-2,5 G/H
- Mfr：DIT
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：30 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, ENEC, SEMKO, UL, UR
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：290 V
- Voltage - Rated AC (Phase to Phase)：500 V
Power Line Filter Modules datasheet and documents for TB6-5030D3DH
Power Line Filter Modules Overview
The TB6-5030D3DH is a three-phase delta EMC/EMI line filter module manufactured by DIT. It is designed for chassis mounting and supports a current rating of 30 A at frequencies between 50 Hz and 60 Hz. The unit utilizes a two-stage filtering architecture to suppress electromagnetic interference in power distribution systems.
Power Line Filter Modules Feature Summary
- Two-stage filtering architecture for enhanced noise suppression
- Chassis mounting design for industrial integration
- Terminal block connection interface
Power Line Filter Modules Applications
- High-power motor control cabinets
- Industrial power distribution units
- EMC compliance testing equipment
Power Line Filter Modules Procurement Notes
Verify the specific phase configuration (Delta) and current rating (30A) against system requirements before ordering. Confirm that the chassis mounting style and terminal block connections are compatible with the installation environment. Ensure the input frequency range of 50-60Hz matches the local power grid standards.
Power Line Filter Modules Selection Notes
Select this component when a robust, two-stage EMI solution is required for three-phase delta systems. Consider the physical dimensions and mounting constraints associated with chassis installation. Evaluate the thermal performance within the enclosure to ensure stable operation under continuous 30A load conditions.
Power Line Filter Modules Part Context
This model belongs to DIT's series of power line filter modules. These components are engineered to meet stringent electromagnetic compatibility standards in industrial environments. The product line focuses on providing reliable noise attenuation for sensitive electronic equipment connected to main power lines.
Power Line Filter Modules Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing mounting hardware and electrical specifications if considering alternative manufacturers.
