TB6-5080D3DH

Power Line Filter Modules Overview

The TB6-5080D3DH is a three-phase (Delta) EMC/EMI line filter module manufactured by DIT. It is rated for 80 A current and operates at 50 to 60 Hz. The unit features a two-stage filtering design with terminal block connections. It is housed in a chassis-mount configuration designed for industrial power line applications.

Power Line Filter Modules Feature Summary

• Three-phase Delta topology for balanced load filtering
• Two-stage attenuation architecture for enhanced noise suppression
• Terminal block interface for secure electrical connections

Power Line Filter Modules Applications

• Industrial power distribution systems
• Electromagnetic interference mitigation in heavy machinery
• Compliance with electromagnetic compatibility standards

Power Line Filter Modules Procurement Notes

Verify the specific phase configuration matches the Delta requirement before integration. Confirm that the 80 A rating aligns with the maximum continuous load of the target circuit. Ensure the chassis mounting style fits the available enclosure space. Check for any specific environmental ratings if operating in extreme temperatures.

Power Line Filter Modules Selection Notes

Select this component when a robust, high-current solution is required for three-phase Delta networks. The two-stage design offers superior performance compared to single-stage alternatives. Consider the physical dimensions and terminal block type during mechanical layout planning to ensure proper wiring access.

Power Line Filter Modules Part Context

This model belongs to the DIT power line filter series, which focuses on electromagnetic compatibility solutions. These modules are engineered to reduce conducted emissions and improve immunity in industrial environments. The product line typically includes various current ratings and phase configurations to suit different power system requirements.
