TB6-B010NBDC

Power Line Filter Modules Overview

The TB6-B010NBDC is a three-phase (Delta) EMC/EMI line filter module manufactured by DIT. It is rated for a current of 10 A and operates at frequencies of 50 to 60 Hz. The unit features a two-stage filtering design with terminal block connections. It is housed in a chassis-mount configuration and is RoHS compliant.

Power Line Filter Modules Feature Summary

• Two-stage EMC/EMI filtering architecture
• Metal enclosure providing effective shielding
• Epoxy resin potting for durability
• Terminal block connection method

Power Line Filter Modules Applications

• Industrial equipment such as CNC machines
• Inverters and converters
• Telecommunications equipment
• Factory automation devices
• Elevator systems

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB6-B010NBDC to confirm mechanical dimensions and mounting hole patterns. Ensure the input voltage rating matches the Delta three-phase system requirements. Check for any specific CE or SEMKO+ENEC certification documentation if required for regional compliance. Confirm the terminal block type aligns with existing wiring infrastructure.

Power Line Filter Modules Selection Notes

Select this component when a three-phase Delta configuration is required for noise suppression. The 10 A rating suits moderate power applications. Consider the chassis mount style for integration into control panels. Verify that the operating temperature range of -25°C to +100°C meets environmental conditions. Ensure the two-stage design provides sufficient attenuation for the specific EMI/EMI profile.

Power Line Filter Modules Part Context

This part belongs to the TB6-B series of power line filters from DIT. The series includes various current ratings, such as 16 A and 20 A models. These filters are designed for industrial environments requiring robust electromagnetic interference reduction. The series utilizes epoxy potting and metal housings for reliability.

Power Line Filter Modules Replacement Considerations

Check for other TB6-B series variants like TB6-B016NBDC for higher current needs. Verify compatibility with existing panel space and terminal block types. Ensure substitute parts maintain the same three-phase Delta configuration and voltage ratings.
