TB6-B016NBDC

Power Line Filter Modules Overview

The TB6-B016NBDC is a three-phase (Delta) EMC/EMI line filter manufactured by DIT. It features a two-stage design with terminal block connections and is rated for 16 A at 50 ~ 60Hz. The unit operates within a temperature range of -25°C to +100°C, including temperature rise. It utilizes a metal case for shielding and epoxy resin potting.

Power Line Filter Modules Feature Summary

• Three-phase filtering capability
• Metal case construction for good shield effect
• Epoxy resin potted design

Power Line Filter Modules Applications

• Industrial equipment noise suppression

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the TB6-B016NBDC to confirm exact dimensional tolerances and mounting hole patterns. Ensure the input voltage and frequency ratings match the target system requirements before integration. Confirm RoHS compliance status through official manufacturer documentation rather than distributor summaries.

Power Line Filter Modules Selection Notes

Select this component when a two-stage EMI/EMC solution is required for three-phase Delta systems. The 16 A rating suits moderate current applications. Consider the chassis mount form factor and terminal block interface for panel integration. Verify thermal management needs given the operating temperature limits.

Power Line Filter Modules Part Context

This part belongs to the TB6-B series of power line filters from Dong Il Technology (DIT). The series includes various current ratings such as 6A, 8A, and 20A models. These filters are designed for industrial environments requiring robust electromagnetic interference reduction.

Power Line Filter Modules Replacement Considerations

Cross-reference with other TB6-B series models like TB6-B006NBDC or TB6-B020NBDC if current ratings differ. Verify that substitute parts maintain the same three-phase Delta configuration and terminal block connection style.
