TB6-B020NBDC

Power Line Filter Modules Overview

The TB6-B020NBDC is a three-phase (Delta) EMC/EMI line filter module manufactured by DIT. It features a two-stage terminal block design and is rated for 20 A current at 50-60 Hz operating frequencies. The unit supports AC voltage ratings of 440 V phase-to-phase and 254 V phase-to-ground. Constructed with an epoxy resin potting and a metal case, it provides electromagnetic interference filtering for industrial applications.

Power Line Filter Modules Feature Summary

• Two-stage terminal block configuration for enhanced filtering performance
• Metal case construction providing effective electromagnetic shielding
• Epoxy resin potting for environmental protection and durability

Power Line Filter Modules Applications

• General-purpose industrial equipment
• Three-phase power distribution systems
• Electromagnetic compatibility (EMC) mitigation in Delta configurations

Power Line Filter Modules Procurement Notes

Verify the specific part number TB6-B020NBDC against official DIT documentation to confirm electrical ratings and physical dimensions. Ensure compatibility with three-phase Delta systems requiring 20 A capacity. Request manufacturer datasheets for precise mounting and wiring specifications before integration.

Power Line Filter Modules Selection Notes

Select this component when three-phase EMI suppression is required for industrial loads up to 20 A. The two-stage design offers superior attenuation compared to single-stage alternatives. Confirm that the 440 V phase-to-phase rating aligns with the target system voltage requirements.

Power Line Filter Modules Part Context

This model belongs to the TB6 series of power line filter modules from DIT. These units are designed for robust industrial environments, utilizing potted epoxy and metal enclosures to ensure reliability under varying thermal and mechanical conditions while maintaining signal integrity.
