TB6-B030NBDC

Power Line Filter Modules Overview

The TB6-B030NBDC is a three-phase EMC/EMI line filter module rated for 30 A at 50–60 Hz. It supports 440 V phase-to-phase and 254 V phase-to-ground AC voltages. The unit features a two-stage filtering architecture with terminal block connections. Designed for general-purpose industrial applications, it operates within a temperature range of -25°C to +85°C. The component holds CE, CSA, ENEC, and SEMKO approvals.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Epoxy resin potted construction for environmental protection
• Metal shielding provides effective high voltage impulse attenuation
• Terminal block interface for secure electrical connections

Power Line Filter Modules Applications

• General-purpose industrial machinery
• Drive-rated equipment input stages
• Three-phase power distribution systems

Power Line Filter Modules Procurement Notes

Verify the specific ordering suffix against official DIT documentation to confirm terminal type and mounting configuration. Ensure the application voltage does not exceed the 440 V phase-to-phase rating. Confirm that the required current capacity aligns with the 30 A nominal rating under specified operating temperatures. Check for necessary regulatory certifications such as CE or CSA for your target market compliance requirements before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this model when a two-stage EMI/EMI solution is required for three-phase circuits carrying up to 30 A. It is suitable for environments requiring epoxy-potted components for vibration resistance. Consider the terminal block connection style if chassis or panel mounting with screw terminals is preferred over other interface types. Verify space constraints against the physical dimensions provided in the official datasheet.

Power Line Filter Modules Part Context

This component belongs to the TB6 series of power line filter modules manufactured by DIT. These filters are engineered for electromagnetic compatibility in industrial settings. The series typically offers various current ratings and voltage configurations to suit different three-phase power requirements while maintaining compact form factors for panel integration.

Power Line Filter Modules Replacement Considerations

Cross-reference with LS Electric EMI input filters for similar three-phase, 30 A specifications. Verify that alternative models match the two-stage performance characteristics and terminal block interface requirements. Ensure voltage ratings and approval agencies align with existing system standards.
