TB6-B060LAS is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FILTER 60A CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for TB6-B060LAS
- Description：LINE FILTER 60A CHASSIS MOUNT
- Series：TB6-B
- Mfr：DIT
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：60 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, CSA, ENEC, SEMKO
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：254 V
- Voltage - Rated AC (Phase to Phase)：440 V
Power Line Filter Modules datasheet and documents for TB6-B060LAS
Power Line Filter Modules Overview
The TB6-B060LAS is a three-phase (Delta) EMC/EMI line filter manufactured by DIT. It is rated for a current of 60 A and operates at frequencies between 50 Hz and 60 Hz. The unit features a single-stage design with terminal block connections. This component is engineered to suppress electromagnetic interference in power systems.
Power Line Filter Modules Feature Summary
- Provides superior noise suppression for EMI filtering applications
- Engineered to minimize system noise and interference
- Features robust construction for reliable operation
Power Line Filter Modules Applications
- Three-phase Delta power line filtering
- EMC/EMI noise reduction in industrial equipment
- Power supply interference mitigation
Power Line Filter Modules Procurement Notes
Verify the specific suffix 'S' against the manufacturer's official documentation to confirm terminal configuration and mounting details. Ensure the 60 A rating and Delta phase compatibility match the target circuit requirements before procurement. Cross-reference the part number with the latest datasheet to avoid substitution errors.
Power Line Filter Modules Selection Notes
Select this model for three-phase Delta systems requiring 60 A filtering capacity. Confirm that the terminal block interface suits the existing wiring infrastructure. Evaluate the single-stage attenuation performance against specific EMI standards required by the application environment.
Power Line Filter Modules Part Context
This component belongs to the TB6 series of power line filters from Dong Il Technology (DIT). The series includes various ratings and configurations for three-phase applications. The TB6-B060LAS specifically addresses high-current Delta network noise suppression needs.
Power Line Filter Modules Replacement Considerations
Consult the official TB6-B series datasheet for direct substitutes. Verify electrical ratings and physical dimensions when considering alternative models from the same manufacturer or competitors.
