TB6-B100LAS

Power Line Filter Modules Overview

The TB6-B100LAS is a three-phase EMC/EMI power line filter module manufactured by DIT. It is designed for AC systems operating at 50 to 60 Hz with a rated current of 100 A. The unit features a single-stage filtering configuration and utilizes a terminal block connection method. Constructed with an epoxy resin potting process, it employs a metal case to provide effective shielding against electromagnetic interference. The component supports differential and common mode noise suppression and operates within a temperature range of -25°C to 100°C.

Power Line Filter Modules Feature Summary

• Three-phase design with epoxy resin potting for durability
• Metal case construction providing effective electromagnetic shielding
• Terminal block interface for secure electrical connections

Power Line Filter Modules Applications

• Industrial equipment such as CNC machines
• Inverter and converter systems
• Telecommunications infrastructure
• Factory automation (FA) devices
• Elevator control systems

Power Line Filter Modules Procurement Notes

Verify the specific suffix LAS corresponds to the required terminal block configuration and voltage rating. Confirm CE, CSA, ENEC, and SEMKO approvals are valid for your target market. Ensure the 100 A current rating matches the load requirements. Check that the operating temperature range suits the installation environment. Validate the three-phase delta connection compatibility before purchase.

Power Line Filter Modules Selection Notes

Select this model when high-current three-phase filtering is required in industrial settings. The metal housing offers superior shielding compared to plastic alternatives. The epoxy potting ensures resistance to environmental stressors. Consider the terminal block style for ease of wiring integration. Verify that the single-stage design meets the specific EMI reduction needs of the application.

Power Line Filter Modules Part Context

This component belongs to the TB6 series of power line filter modules from Dong Il Technology (DIT). The series includes various current ratings and configurations for three-phase applications. These filters are engineered to suppress conducted emissions in AC power lines. The TB6-B100LAS specifically addresses high-current requirements up to 100 A.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the TB6 series with matching current ratings. Verify compatibility with existing mounting structures due to the metal case dimensions. Ensure replacement units maintain the same approval certifications. Confirm the terminal block type matches the existing wiring harness.
