Product Detailed Parameters
- Description：IC MOTOR DRIVER 7V-42V 36HSOP
- Series：-
- Mfr：Toshiba Semiconductor and Storage
- Package：Tape & Reel (TR),Cut Tape (CT)
- Motor Type - Stepper：-
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Driver - Fully Integrated, Control and Power Stage
- Output Configuration：Half Bridge (3)
- Interface：Parallel
- Technology：Power MOSFET
- Step Resolution：-
- Applications：General Purpose
- Current - Output：1.5A
- Voltage - Supply：7V ~ 42V
- Voltage - Load：7V ~ 42V
- Operating Temperature：-30°C ~ 105°C (TA)
- Mounting Type：Surface Mount
- Package / Case：36-BSSOP (0.346", 8.80mm Width) + 2 Heat Tabs
- Supplier Device Package：36-HSOP
- Grade：-
- Qualification：-
Download product information
Overview
The TB6588FG,8,EL,JU is a fully integrated three-phase brushless DC motor driver manufactured by Toshiba Semiconductor and Storage. It operates within a supply voltage range of 7V to 42V and supports a continuous output current of 1.5A per phase. The device utilizes a parallel interface for control signals and incorporates power MOSFET technology for the output stage. Packaged in a 36-HSOP format with two thermal pads, it is designed for surface mount installation. The component functions as a complete driver including control and power stages, suitable for applications requiring robust motor management across an operating temperature range of -30°C to 105°C.
Feature Summary
- Fully integrated design combining control logic and power MOSFET output stages
- Supports sensorless BLDC motor control architectures
- Includes built-in protection mechanisms for reliable operation
Applications
- Sensorless Brushless DC (BLDC) motor controllers
- General purpose industrial automation drives
- Home appliance motor control systems
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct packaging and pin configuration. Confirm that the requested part number matches the exact electrical specifications required for the target application. Cross-reference the RoHS status and moisture sensitivity level with project compliance requirements before finalizing procurement orders.
Selection Notes
Select this component when a single-chip solution for three-phase BLDC motors is required. Ensure the system voltage remains within the 7V to 42V operational window. Consider the thermal performance of the 36-HSOP package if high ambient temperatures are expected. Verify that the parallel interface compatibility aligns with the microcontroller or control unit being utilized in the design.
Part Context
This part belongs to the TB6588 series of motor drivers from Toshiba. The series focuses on providing integrated solutions for brushless DC motor applications. The TB6588FG variant specifically addresses the need for compact, high-efficiency driving circuits. It serves as a core component in motion control systems where space constraints and integration levels are critical design factors.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's official replacement guide or contact technical support directly for validated alternative components.
