TBB-10BDD3B

Power Line Filter Modules Overview

The TBB-10BDD3B is a single-phase EMC/EMI power line filter module manufactured by DONG IL TECHNOLOGY LTD. It is rated for 10 A current and operates at 250 V AC or DC within the 50 to 60 Hz frequency range. The component features a maximum leakage current of 0.5 mA and functions reliably between -25°C and +85°C. It utilizes terminal block connections and supports both screw and DIN rail mounting configurations.

Power Line Filter Modules Feature Summary

• Screw and DIN rail mountable design for flexible installation
• Excellent filtering characteristics for differential mode noise
• Easy connection and installation via terminal block interface

Power Line Filter Modules Applications

• General purpose electromagnetic interference suppression
• Single-phase power line filtering in industrial equipment
• EMC compliance enhancement for electronic devices

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation as DONG IL TECHNOLOGY LTD when sourcing this component. Confirm the specific suffix '3B' corresponds to the 0.5 mA leakage current rating, distinct from the 'DB' variant which specifies 0.1 mA. Ensure the ordering information matches the required electrical ratings and mounting style for your application.

Power Line Filter Modules Selection Notes

Select this model when a 10 A capacity is required for single-phase applications. Consider the 0.5 mA leakage current specification against safety standards. Compare with other TBB series variants if different current ratings or lower leakage currents are necessary for the specific system requirements.

Power Line Filter Modules Part Context

This component belongs to the TBB Series of power line filter modules produced by DONG IL TECHNOLOGY LTD. The series includes various current ratings such as 6 A, 10 A, 16 A, and 20 A. The TBB-10BDD3B specifically denotes the 10 A version with its associated leakage current and voltage specifications.

Power Line Filter Modules Replacement Considerations

Other models in the TBB series may serve as substitutes depending on current and leakage current requirements. For instance, the TBB-10BDDDB offers the same 10 A rating but with a lower 0.1 mA leakage current. Verify compatibility before substitution.
