TBB-16BDD3B

Power Line Filter Modules Overview

The TBB-16BDD3B is a single-phase EMC/EMI line filter module manufactured by DIT. It features a rated AC voltage of 250V and a continuous current capacity of 16A, operating at frequencies between 50Hz and 60Hz. The device utilizes terminal block connections for installation. Key electrical specifications include a maximum leakage current of 0.5mA and a dielectric strength test voltage of 1500V AC applied for one minute between line and ground.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for general-purpose applications
• Single-stage filtering design integrated into a compact module
• Terminal block connection method for straightforward wiring

Power Line Filter Modules Applications

• General-purpose power line filtering
• EMC/EMI noise reduction in AC circuits
• Industrial equipment power input stages

Power Line Filter Modules Procurement Notes

Verify the specific part number against manufacturer documentation to confirm ratings. Ensure compatibility with 250V AC systems and 16A load requirements. Check for required certifications such as CE or cCSAus based on regional regulations. Confirm terminal block type matches existing infrastructure before procurement.

Power Line Filter Modules Selection Notes

Select this component when single-phase EMI suppression is required for loads up to 16A at 250V. Consider the terminal block interface for mounting constraints. Evaluate leakage current limits if sensitive downstream electronics are present. Verify frequency range compatibility with local power standards.

Power Line Filter Modules Part Context

This model belongs to the TBB series of power line filter modules from DIT. The series includes variants with different current ratings, such as 6A, 10A, and 20A options. These filters are designed for standard AC power line applications requiring basic electromagnetic interference mitigation.

Power Line Filter Modules Replacement Considerations

Cross-reference with other TBB series models like TBB-10BDD3B or TBB-20BDD3B if current ratings differ. Verify that substitute components maintain the same 250V rating and terminal block configuration to ensure mechanical and electrical compatibility.
