TC1793F512F270EBABKXUMA1

Microcontrollers Overview

The TC1793F512F270EBABKXUMA1 is a 32-bit single-chip microcontroller from the TC17xx family, featuring a TriCore V1.6 CPU operating at 270 MHz and a PCP2 core at 200 MHz. It includes 4 Mbyte Program Flash with ECC, 192 Kbyte Data Flash, and 128 Kbyte SRAM. The device provides 221 digital I/O lines, supports 3.3 V logic, and integrates interfaces including MultiCAN (4 nodes), FlexRay, SSC, ASC, SENT, MSC, and EBU.

Microcontrollers Feature Summary

• Integrates a high-performance super-scalar TriCore V1.6 CPU with fully pipelined FPU and DSP capabilities for superior real-time processing.
• Features a dedicated Peripheral Control Processor (PCP2) to handle standalone data operations and interrupt servicing independently of the main CPU.
• Includes a sophisticated interconnect structure with a 64-bit Cross Bar Interconnect and System Peripheral Bus for high bandwidth communication.
• Supports automotive safety standards through integrated error detection mechanisms such as ECC on memory modules.

Microcontrollers Applications

• Automotive engine control units requiring high computational power
• Advanced driver assistance systems (ADAS)
• Body electronics and gateway applications
• Industrial motor control systems

Microcontrollers Procurement Notes

Verify the specific ordering suffix against the manufacturer's product catalog to confirm package type and delivery format. Ensure compatibility with existing PCB footprints by checking the PG-BGA-416 pin configuration. Confirm that the selected derivative meets the required ambient temperature range specifications for the target application environment.

Microcontrollers Selection Notes

Select this component when a combination of high-speed processing and extensive peripheral connectivity is required. The inclusion of both FlexRay and MultiCAN makes it suitable for complex network topologies. Consider the available scratch-pad RAM and cache sizes if low-latency execution is critical for the software architecture.

Microcontrollers Part Context

This microcontroller belongs to the TC17xx series, designed for demanding embedded control tasks. It combines RISC architecture with DSP addressing modes to efficiently analyze signals while maintaining low system costs. The device is optimized for applications where price/performance ratios and real-time responsiveness are primary design constraints.

Microcontrollers Replacement Considerations

Consult the official product catalog for derivatives within the TC1793 family that may offer different clock speeds or feature sets. Verify pin-to-pin compatibility before substituting with other packages in the same series.
