TCK-147

$2.12

Description：FIXED IND 15UH 600MA 600MOHM SMD
Series：-
Mfr：Traco Power
Package：Strip

SKU:98f9e4d40617 Category: Fixed Inductors Brand: Traco Power

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TCK-147 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Traco Power. Its product description is FIXED IND 15UH 600MA 600MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for TCK-147

Description：FIXED IND 15UH 600MA 600MOHM SMD
Series：-
Mfr：Traco Power
Package：Strip
Type：-
Material - Core：-
Inductance：15 µH
Tolerance：±20%
Current Rating (Amps)：600 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：600mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：1 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.138" L x 0.122" W (3.50mm x 3.10mm)
Height - Seated (Max)：0.102" (2.60mm)
Features：-

Fixed Inductors datasheet and documents for TCK-147

TCK-147

Fixed Inductors Overview

The TCK-147 is a common mode choke manufactured by Traco Power, designed for use with isolated DC-DC converters. It features an inductance of 15 µH at a test frequency of 100 kHz and supports a maximum rated current of 0.6 A. The component has a maximum DC resistance (DCR) of 600 mΩ. It utilizes a surface-mount device (SMD) package with dimensions of 3.1 mm x 3.5 mm x 2.1 mm. The unit operates within a temperature range of -40°C to +125°C.

Fixed Inductors Feature Summary

Designed specifically for use with Traco isolated DC-DC converters
Surface-mount construction for automated PCB assembly
Wide operating temperature range suitable for demanding environments

Fixed Inductors Applications

Input filtering for isolated DC-DC converter modules
EMI suppression in industrial control equipment
Power supply stages in measurement instruments

Fixed Inductors Procurement Notes

Verify the specific package variant when ordering, as surface-mount components may have distinct footprint requirements. Confirm that the 0.6 A current rating aligns with the system's peak load demands. Ensure the 15 µH inductance value meets the noise attenuation specifications of the target circuit design before finalizing procurement.

Fixed Inductors Selection Notes

Select this component when integrating Traco Power isolated converters requiring compact EMI filtering. The 15 µH value provides effective common-mode noise reduction for low-current applications up to 0.6 A. Consider the SMD footprint constraints and the 600 mΩ DCR impact on efficiency during the schematic design phase.

Fixed Inductors Part Context

The TCK series comprises common mode chokes engineered to complement Traco Power's range of isolated DC-DC converters. These components are intended to enhance electromagnetic compatibility in power supply circuits. The TCK-147 represents a specific variant optimized for lower current applications compared to higher-capacity models in the same family.
