TCK-166

$3.08

Description：PWR SUPP, SUPPLIES & COND
Series：-
Mfr：Traco Power
Package：Strip

SKU:4e4ac199063f Category: Fixed Inductors Brand: Traco Power

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TCK-166 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Traco Power. Its product description is PWR SUPP, SUPPLIES & COND. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for TCK-166

Description：PWR SUPP, SUPPLIES & COND
Series：-
Mfr：Traco Power
Package：Strip
Type：-
Material - Core：-
Inductance：8.2 µH
Tolerance：±20%
Current Rating (Amps)：9:00 AM
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：27mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)：0.157" (4.00mm)
Features：-

Fixed Inductors datasheet and documents for TCK-166

TCK-166

Fixed Inductors Overview

The TCK-166 is a surface-mount power inductor from the Traco Power TCK series. It features an inductance of 8.2 µH with a tolerance of ±20%. The component supports a rated current of 9 A and exhibits a maximum DC resistance of 27 mΩ. Designed for non-standard packaging, it operates within a temperature range of -40°C to +125°C.

Fixed Inductors Feature Summary

High current handling capability suitable for power supply applications
Unshielded construction for flexible layout integration
Surface-mount technology for automated PCB assembly

Fixed Inductors Applications

Embedded systems power distribution
Industrial automation control circuits
General electronics power filtering

Fixed Inductors Procurement Notes

Verify part authenticity by sourcing exclusively through authorized Traco Power partners to prevent counterfeits. Confirm RoHS3 compliance and REACH status during procurement. Ensure standard lead times are accounted for in production schedules. Validate that the non-standard package dimensions match the target PCB footprint requirements before finalizing orders.

Fixed Inductors Selection Notes

Select this component when high current capacity is required alongside low impedance characteristics. The unshielded design allows for strategic placement to minimize magnetic interference with nearby sensitive components. Verify that the operating temperature range meets the environmental conditions of the specific application board.

Fixed Inductors Part Context

The TCK-166 belongs to the TCK series of fixed power inductors manufactured by Traco Power. This series utilizes SMD technology to provide reliable performance in space-critical designs. The component is distinct from other series like TMA converters, focusing specifically on passive filtering and energy storage functions.
