Product Detailed Parameters
- Description：CMC 100MA 2LN 8 OHM SMD
- Series：TCM-T
- Mfr：TDK Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Filter Type：Signal Line
- Number of Lines：2
- Current Rating (Max)：100mA
- DC Resistance (DCR) (Max)：2Ohm
- Voltage Rating - DC：10V
- Voltage Rating - AC：-
- Operating Temperature：-25°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Surface Mount
- Size / Dimension：0.026" L x 0.020" W (0.65mm x 0.50mm)
- Height (Max)：0.014" (0.35mm)
- Package / Case：0202 (0505 Metric), 4 PC Pad
- Inductance @ Frequency：-
- Impedance @ Frequency：8 Ohms @ 100 MHz
- Qualification：-
- Grade：-
Download product information
Overview
The TCM0605T-080-2P-T201 is a two-channel ultra-high-speed common mode filter manufactured by TDK Corporation. It features an unshielded SMD/SMT construction with a compact footprint of 0.65 mm x 0.5 mm x 0.35 mm. The component provides a common mode impedance of 8 Ohms at a test frequency of 100 MHz and supports a maximum DC current of 100 mA. Its electrical characteristics include an inductance of 12 nH and a maximum DC resistance of 2 Ohms. Designed for signal line applications, it operates within a temperature range of -25°C to +85°C.
Feature Summary
- Ultra-high speed filtering capability designed for high-frequency signal integrity
- Compact 0605 surface-mount package optimized for space-constrained PCB layouts
- Unshielded construction suitable for general EMI suppression tasks
Applications
- High-speed signal line EMI suppression
- Portable electronic devices requiring miniaturized components
- Data transmission interfaces
Procurement Notes
Verify the manufacturer part number against official TDK documentation to ensure authenticity. Confirm that the received components match the specified 0605 package dimensions and electrical ratings. Check for physical damage or contamination before soldering. Ensure storage conditions comply with moisture sensitivity levels if applicable. Cross-reference ordering information with authorized distributors to avoid counterfeit products.
Selection Notes
Select this component when a low-profile, two-channel common mode choke is required for high-speed digital signals. The 8 Ohm impedance at 100 MHz makes it suitable for moderate noise attenuation needs. Consider the 100 mA current rating to ensure it meets the circuit's operational requirements. The unshielded design may influence placement relative to sensitive analog traces.
Part Context
This component belongs to the TCM-T series of ultra-compact common mode chokes from TDK. The series is characterized by its small form factor and suitability for modern electronics where board space is limited. It serves as a passive electromagnetic interference suppression device for differential and single-ended signal lines.
Replacement Considerations
Consult TDK official documentation for verified equivalent part numbers within the TCM-T series. Ensure any substitute matches the 0605 footprint, 8 Ohm impedance, and 100 mA current rating. Verify compatibility with existing PCB land patterns and thermal profiles.
