TD-8.000MBD-T

Oscillators Overview

The TD-8.000MBD-T is a standard CMOS MEMS oscillator manufactured by TXC Corporation, operating at a nominal frequency of 8 MHz. It features a supply voltage range of 1.8 V to 3.3 V and offers a frequency stability of ±25 ppm. The device supports an enable/disable function and operates within a temperature range of -40°C to +85°C. It is housed in a compact 4-SMD, No Lead package with dimensions of 2.50 mm x 2.00 mm x 0.80 mm maximum height.

Oscillators Feature Summary

• Utilizes MEMS technology for reliable clock generation
• Supports active high or low enable/disable control
• Provides CMOS output format for digital interfacing

Oscillators Applications

• Embedded systems requiring precise timing
• Consumer electronics with space constraints
• Industrial control modules

Oscillators Procurement Notes

Verify the specific supply voltage requirement (1.8V or 3.3V) against your circuit design before procurement. Confirm that the enable/disable pin configuration matches your system logic levels. Ensure the operating temperature range of -40°C to +85°C meets environmental specifications. Check current consumption limits against power budget constraints.

Oscillators Selection Notes

Select this component when a small form factor and robust MEMS performance are required. It is suitable for applications needing a standard CMOS interface without external load capacitors. Consider the enable/disable feature if power management is critical. Verify compatibility with the target system's voltage rails and thermal environment.

Oscillators Part Context

This part belongs to the TD series of MEMS oscillators from TXC Corporation. It represents a silicon-based alternative to traditional quartz crystals, offering improved shock resistance and smaller footprint. The series is designed for surface-mount assembly in modern electronic devices requiring stable clock signals.

Oscillators Replacement Considerations

Direct substitutes include other 8 MHz MEMS oscillators with identical 4-SMD footprints and CMOS outputs. Ensure replacement parts match the ±25 ppm stability and -40°C to +85°C temperature range. Verify that any alternative also supports the required enable/disable functionality and voltage levels.
