TE0115A

$2.63

Description：SAW DIPLEXER, SM5050-8PAD, 390.0
Series：-
Mfr：TST
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:048c3baaf761 Category: SAW Filters Brand: TST

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：SAW DIPLEXER, SM5050-8PAD, 390.0
Series：-
Mfr：TST
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency - Center：390MHz, 420MHz
Bandwidth：20MHz
Insertion Loss：3.3dB
Ratings：-
Applications：Wireless
Mounting Type：Surface Mount
Package / Case：8-SMD, No Lead
Height (Max)：0.067" (1.70mm)
Size / Dimension：0.197" L x 0.197" W (5.00mm x 5.00mm)

Download product information

TE0115A

Overview

The TE0115A is a dual-channel Surface Acoustic Wave (SAW) filter manufactured by Tai-Saw Technology Co., Ltd. It operates at center frequencies of 390 MHz and 420 MHz, designed for wireless RF applications. The component features a bandwidth of 20 MHz and an insertion loss of 3.3 dB. It is housed in an 8-SMD, no-lead package with dimensions of 5.0x5.0x1.7 mm.
