TE0600-03IVFN

Overview

The TE0600-03IVFN is a System-on-Module (SOM) manufactured by Trenz Electronic GmbH, designed for programmable logic applications. It integrates the AMD Xilinx Spartan-6 LX FPGA as its core processing unit. The module features an integrated memory subsystem comprising 256Mb of DDR3 SDRAM and 16MB of SPI Flash storage. It operates within a commercial temperature range and utilizes a Samtec LSHM connector interface for carrier board integration.

Feature Summary

• Integrates AMD Xilinx Spartan-6 LX FPGA for programmable logic implementation
• Includes onboard 256Mb DDR3 SDRAM and 16MB SPI Flash memory
• Utilizes Samtec LSHM connector interface for reliable carrier board connection

Applications

• Programmable logic development
• Embedded computing systems
• Industrial control modules

Procurement Notes

Verify component authenticity through authorized Trenz Electronic distributors or official channels. Confirm that the specific revision matches project requirements, particularly regarding the Samtec connector type and memory configuration. Ensure compliance with CE and UKCA standards if applicable to the target market. Check current supply status as availability may vary.

Selection Notes

Select this module when a compact SOM solution based on the Spartan-6 architecture is required. It is suitable for designs needing integrated DDR3 and Flash without external components. Consider the commercial temperature range limitations. Evaluate pin availability against the specific FPGA I/O requirements of the application before finalizing the design.

Part Context

This part belongs to the Trenz Electronic TE0600 series of System-on-Modules. These modules are engineered to simplify the integration of Xilinx FPGAs into custom carrier boards. The series provides a standardized form factor and connector interface, reducing design complexity for developers utilizing Spartan-6 technology in embedded environments.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult Trenz Electronic directly for legacy support or alternative recommendations within the same product family.
