TE0711-01-100-2C

Microcontrollers, Microprocessor, FPGA Modules Overview

The TE0711-01-100-2C is a System-on-Module (SOM) manufactured by Trenz Electronic GmbH, designed for programmable logic applications. It features the AMD Artix 7A100T FPGA as its core processor. The module operates at an input supply voltage of 3.3 V and supports a functional temperature range from 0°C to +70°C. It includes 32 MB of flash memory storage. The physical dimensions are standardized in a 4 x 5 cm form factor.

Microcontrollers, Microprocessor, FPGA Modules Feature Summary

• Integrates the AMD Artix 7A100T FPGA for high-performance programmable logic processing.
• Provides 32 MB of non-volatile flash memory for data storage and configuration.
• Designed with a compact 4 x 5 cm footprint suitable for space-constrained embedded systems.

Microcontrollers, Microprocessor, FPGA Modules Applications

• Industrial automation control systems
• Embedded signal processing units
• Custom hardware prototyping platforms

Microcontrollers, Microprocessor, FPGA Modules Procurement Notes

Verify component authenticity through official Trenz Electronic channels or authorized distributors. Confirm that the specific speed grade suffix '2C' matches the required performance specifications for the target application. Ensure compliance with CE and UKCA standards if deploying in regulated markets. Check current availability status as supply levels may fluctuate.

Microcontrollers, Microprocessor, FPGA Modules Selection Notes

Select this module when a dedicated FPGA solution based on the Artix 7 architecture is required. The 3.3 V operating voltage dictates power supply design considerations. The industrial temperature range suitability should be validated against environmental conditions. Compare pinout compatibility with existing carrier board designs before integration.

Microcontrollers, Microprocessor, FPGA Modules Part Context

This module belongs to the TE0711 series of High IO Xilinx Artix-7 modules produced by Trenz Electronic. It serves as a modular computing element within their embedded solutions portfolio. The product line focuses on providing reliable FPGA cores in standardized form factors for rapid development cycles.

Microcontrollers, Microprocessor, FPGA Modules Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Users requiring alternative components must evaluate other SOM manufacturers or different FPGA families independently.
