TEL 8-2422WI

TEL 8-2422WI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is DC DC CONVERTER +/-12V 8W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TEL 8-2422WI

• Description：DC DC CONVERTER +/-12V 8W
• Series：TEL 8WI (8W)
• Mfr：Traco Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：335mA, 335mA
• Power (Watts)：8 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 80°C (With Derating)
• Efficiency：85%
• Mounting Type：Through Hole
• Package / Case：16-DIP Module, 6 Leads
• Size / Dimension：0.95" L x 0.55" W x 0.33" H (24.1mm x 14.0mm x 8.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for TEL 8-2422WI
