TEM-115-02-07.0-H-D-LC

Headers, Male Pins Overview

The TEM-115-02-07.0-H-D-LC is a .100" (2.54 mm) pitch Tiger Buy™ socket strip manufactured by Samtec Inc. This component features double row configuration with 30 total positions, utilizing high-retention contacts designed for surface mount termination. The part includes a 7.0-inch cable length and incorporates a low-profile (LC) design to minimize vertical space requirements on the printed circuit board.

Headers, Male Pins Feature Summary

• High retention contact system ensures secure mating stability
• Low profile construction reduces overall assembly height
• Integrated cable length facilitates flexible board-to-board connections

Headers, Male Pins Applications

• Surface mount interconnects requiring compact form factors
• Board-to-board connections with flexible cabling needs
• Automotive electronics assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify that the specific suffix LC corresponds to the low-profile variant required for your mechanical constraints. Confirm the 7.0-inch cable length meets spatial routing requirements within the enclosure. Ensure the double row orientation aligns with the mating connector footprint. Cross-reference the UL recognition number E111594 if regulatory compliance documentation is mandatory for the final product submission.

Headers, Male Pins Selection Notes

Select this part when a fixed-length flexible connection is necessary between two PCBs in a confined vertical space. The Tiger Buy™ technology offers cost-effective performance suitable for general purpose applications. Consider the low-profile designation strictly if height restrictions are critical. Evaluate the double row density against pin count requirements to ensure optimal utilization of the available board area without excessive spacing.

Headers, Male Pins Part Context

This component belongs to the Tiger Buy™ Socket Strip family, which provides versatile interconnection solutions. The series supports both through-hole and surface mount terminations across various pitches. The TEM variant specifically integrates cable lengths, distinguishing it from standard rigid socket strips. It serves as a reliable alternative for applications demanding flexibility combined with standard .100" pitch compatibility.
